? Flexible Gigabit access. With flexible 8/24/48 Gigabit access, NSW5130 Series is compatible with non-multiplexed SFP interfaces to enable high density Gigabit access and protect users’ investment.
? Multiple services .NSW5130 Series supports multicast protocols such as IGMP, IGMP Snooping to satisfy the requirements of IP HD video surveillance and other multicast services. Compatible with fast ring network recovery (FRRP) protocol and fast link recovery protocol (FLRP), NSW5130 Series provides a self-recovery performance of less than 20 milliseconds in applications that are prone to lose packets, such as video conferencing and IP HD video surveillance. Multiple services and heavy traffic will have no impact on convergence time, thus ensuring the normal business operation. It uses PoE (Power over Ethernet) technology to remotely supply power to connected devices (such as IP HD cameras, wireless AP, etc) through the Ethernet, eliminating the need of deploying separated power supplies on site and greatly reducing the wiring and management costs of terminals.
? Enhanced environmental adaptability. To satisfy the deployment requirements in different environments, NSW5130 Series adopts an environment-enhanced design, which provides features such as a wide range of operating temperature and pressure, and lightning protection. This helps ensure highly reliable operation in complex electrical environments (e.g., corridor equipment room) and air-conditioning free deployment environments. With low-power consumption hardware and optimized heat dissipation designs of air ducts and component layout, NSW5130 Series ensures fully controllable power consumption. Besides, thanks to running status and environment monitoring, it can make adjustment to fan, interface, PoE power supply and other statuses to reduce energy consumption in accordance with ambient temperature, time period and other operating conditions. A number of statuses and alarms can be provided, including environmental alarms, power supply and fan alarms, interface, and CPU status.
? Sound security control policy. NSW5130 Series provides multiple authentication modes based on MAC address, 802.1x, and Portal. With a built-in authentication server, it supports local access authentication for 256 to 512 users. It supports dynamic or static binding of user identity, such as user account, IP, MAC, VLAN, and interface. Dynamic distribution of policies is supported. NSW5130 Series is provided with enhanced ACL rules by supporting large-capacity ingress and egress ACLs. It also enables ACL distribution based on VLAN, which simplifies user configuration and avoids waste of ACL resources.
? Rich QoS policy. NSW5130 Series supports traffic identification on interfaces. It provides multiple stream classifications based on source MAC address, destination MAC address, source IP address, destination IP address, TCP/UDP port number, protocol type, and VLAN. With priority queues based on hardware, it is compatible with multiple queue scheduling algorithms such as SP, WRR, and SP+WPP. Support congestion management and rate limits on interfaces.
? Outstanding management. With interface mirroring in both inbound and outbound directions, NSW5130 Series can monitor packets on specified interfaces, and copy packets from these interfaces to monitor interface for network detection and troubleshooting. Compatible with SNMPv1/v2/v3 standard network management protocol, NSW5130 Series provides CLI command lines and a Web management interface.
