| PSE | PWR-DC5611-P@NB |
| INPUT | AC 100-240V~ 50/60Hz 2AMax |
| OUTPUT | DC 56V/1.1A (+2%,-4%) |
| Protection/Environmental | |
| Protection | Output over current protection: 1.2A Short circuit protection (Yes) |
| Surge protection power input port meets EN 61000-4-5 criterion B: L-N 2KV L,N-PE 4KV Output communication port :1kV differential mode (criterion B) | |
| Enviromental | |
| Storage Temperature | -40℃~70℃(-40℉~158℉) |
| Operating Temperature | -20℃~60℃(-4℉~140℉) |
| Working humidity | <95% RH |
| Physical Properties | |
| Weight | 473g(1.04lb) |
| Dimension(LxWxH) | 183mmx70.8mmx37mm(7.20”x2.79”x1.46”) |
| Installation mode | Plane installation |
| Color | Black |
| Input plug | 3-pin plug |
| Power Out Pin | Endspan 1.2(+),3.6(-)Midspan 4.5(+),7.8(-) |
| Output plug | 18.5±0.5mm (Network Cable Connector) |
| Safety Standards | |
| Certification | CCC,CB,CE,FCC,UL |
