| Parameter | Description |
| Power supply | DC12V ±25%, IEEE802.3af PoE power supply |
| Card capacity | 10000 |
| Operating system | Linux |
| Illuminator | IR light (adaptive) |
| WDR | Support |
| FOV | Horizontal: 106.9° Vertical: 56.9° Diagonal: 127.9° |
| Power consumption | PoE: 10.73W DC12V: 8.62W |
| Volume adjustment | Support |
| Audio quality | Noise suppression, echo cancellation, AGC |
| Audio input | 1 x Built-in omnidirectional microphone |
| Audio output | 1 x Built-in speaker |
| Audio compression format | PCM, G711, MP3 |
| Audio compression bit rate | 128Kbps |
| Protocol | Private protocol |
| Screen size | 3.97 inch |
| Button | 15 buttons with braille Buttons layout: Row 1: 1/2/3 Row 2: 4/5/6 Row 3: 7/8/9 Row 4: */0/# Row 5: Management center/Call/Cancel |
| Protection level | IP65 (Apply waterproof glue to the gap between the device and the wall. See the corresponding quick guide for details) IK08 |
| Weight | 2.10kg |
| Maximum connected indoor station | 500 |
| Mount method | Wall mount |
| Interface | Power*1, network port*1, RS485*1, IO input*4, IO output*2, door lock*2 (electric lock/door magnet), door opening button*2, door magnet*2, tamper button*1 |
| Network | 100Mbps network port, supports IEEE802.3af PoE power supply |
| Dimensions (L×H×W) | 125mm*358mm*53mm |
| Operating environment | -40°C to 60°C, 10% to 90%, noncondensing, outdoor |
